How to Clear Fault Code DXA8KA on Komatsu PC200-8

 ·
How to Clear Fault Code DXA8KA on Komatsu PC200-8

1. Failure Description

User Code

E02

Failure

PC-EPC (F) Solenoid Coil Circuit Break (Pump Controller System)

Fault Code

DXA8KA

Failure Details

When PC-EPC (F) solenoid coil was driven, circuit break was detected

Controller Response

  • No particular response (Since no current flows, the solenoid doesn’t work);
  • If the cause of failure disappears, the system resets itself.

Problem on Machine

If the pump load increases, the engine speed drops sharply and the engine may stall

Relevant Information

  • The drive current of PC-EPC (F) can be checked with monitoring function (Code: 01300 PC-EPC solenoid coil current (F));
  • Method of reproducing the fault code: Turn the starting switch to the ON position.

Also Applicable to

PC200-8, PC220-8, PC210-8, PC300-8, PC400-8, etc.



2. Troubleshooting

Before getting down to specific troubleshooting, let's take a look at the circuit diagram below first:

Circuit Diagram for PC-EPC (F) and PC-EPC (R) Solenoid Coil System



The following are possible causes and detection methods:

PC-EPC (F) Solenoid Coil Fault (Internal Circuit Break)

  • Detection method: Turn the starting switch to the OFF position, be prepared, and then perform fault diagnosis without turning the starting switch to the ON position.
  • Standard values:

V11 (male)

Resistance value

Between (1) - (2)

7-14Ω



Emergency Pump Drive Switch Fault (Internal Circuit Break)

  • Detection method: Turn the starting switch to the OFF position, be prepared, and then perform fault diagnosis without turning the starting switch to the ON position.
  • Standard values:

S25 (male)

Emergency pump drive switch

Resistance value

Between (3) - (2)

Normal

Max. 1Ω

Emergency

Min. 1MΩ

Between (6) - (5)

Normal

Max. 1Ω

Emergency

Min. 1MΩ



Wiring Harness Circuit Break (Wiring Harness Circuit Break or Poor Connector Contact)

  • Detection method: Turn the starting switch to the OFF position, be prepared, and then perform the fault diagnosis without turning the starting switch to the ON position.
  • Standard values:

Wiring harness

Resistance value

Wiring harness between C02 (female) (96) and S25 (female) (3)

Max. 1Ω

Wiring harness between S25 (female) (2) and V11 (female) (1)

Max. 1Ω

Wiring harness between C02 (female) (115), (117), (120) and S25 (female) (6)

Max. 1Ω

Wiring harness between S25 (female) (5) and V11 (female) (2)

Max. 1Ω



Faulty Pump Controller

  • Detection method: Turn the starting switch to the OFF position, be prepared, and then perform fault diagnosis without turning the starting switch to the ON position.
  • Standard values:

Wiring harness

Resistance value

Between (96) -(115), (117), (120)

7-14Ω



3. Possible Solutions

  • If the problem is with the PC-EPC (F) solenoid coil, emergency pump drive switch or wiring harness, please confirm the part number of the faulty part first and search for the product best suits your need. If you don’t know how to do it, please click here to contact our technician for help;
  • If the problem is with the pumpcontroller, you’re recommended to replace the 7835-46-1007 pump controller. Simply click the button below to place an order:

Notice: The 7835-46-1007 controller is also compatible to 7835-46-10017835-46-1003, 7835-46-10047835-46-1005 and 7835-46-1006. So to ensure we can process the programming for your controller accurately, please send us your part number and machine nameplate for confirmation.



4. More Technical Support

If you need more information or further assistance, please feel free to let us know via live chat or email: service@sinocmp.com, we will reach out to you ASAP.
